Dalsa Spyder3 S3-14-01k40-00-R User Manual

Spyder3 S3-14 and S3-24 Monochrome Camera User's Manual 45
Teledyne DALSA 03-032-20117-01
CCD Shift Direction
When in high sensitivity mode, selects the forward or reverse CCD shift direction, internally or externally
controlled. This accommodates object direction change on a web and allows you to mount the camera
―upside dow n‖.
Camera Link Command
Parameter
Description
Notes
scd i
Shift direction. Allowable values are:
0 = Internally controlled, forward
CCD shift direction.
1 = Internally controlled, reverse
CCD shift direction.
2 = Externally controlled CCD shift
direction via Camera Link control CC3
(CC3=1 forward, CC3=0 reverse).
 To obtain the current value of the exposure
mode, use the command gcp or get scd.
 Available in high sensitivity mode only.
 Refer to Figure 21: Object Movement and
Camera Direction Example using an Inverting
Lens, page 38, for an illustration of when you
should use forward or reverse shift direction.
Example
scd 0
Setting the Camera Link Mode
Sets the camera’s Camera Link configuration, number of Camera Link taps and data bit depth. Refer to
the tables on the following pages to determine which configurations are valid for your camera model and
how this command relates to other camera configuration commands.
Camera Link Command
Parameter
Description
Notes
clm m
Output mode to use:
0: Base configuration, 1 taps, 8 bit output
1: Base configuration, 1 taps, 12 bit output
2: Base configuration, 2 taps, 8 bit output
3: Base configuration, 2 taps, 12 bit output
 To obtain the current Camera Link mode, use
the command gcp or get clm.
 The bit patterns are defined by the Teledyne
DALSA Camera Link Roadmap available here.
Example
clm 0
