76 Spyder3 S3-14 and S3-24 Monochrome Camera User's Manual
03-032-20117-01 Teledyne DALSA
Warning 01: Outside of specification>
Parameter accepted was outside of specified operating range (e.g. gain
greater than ±10 dB of factory setting).
Warning 02: Clipped to min>
Parameter was clipped to the current operating range. Use gcp to see
value used.
Warning 03: Clipped to max>
Parameter was clipped to the current operating range. Use gcp to see
value used.
Warning 04: Related parameters adjusted>
Parameter was clipped to the current operating range. Use gcp to see
value used.
Warning 07: Coefficient may be inaccurate
A/ D clipping has occurred>
In the region of interest (ROI) greater than 6.251% single or 1% of
averaged pixel values were zero or saturated.
Warning 08: Greater than 1% of coefficients
have been clipped>
A FPN/ PRNU has been calculated to be greater than the maximum
allowable 511 (8).
Warning 09: Internal line rate inconsistent
with readout time>
Error 02: Unrecognized command>
Command is not available in the current access level or it is not a valid
command.
Error 03: Incorrect number of parameters>
Error 04: Incorrect parameter value>
This response returned for
· Alpha received for numeric or vice versa
· Not an element of the set of possible values. E.g., Baud Rate
· Outside the range limit
Error 05: Command unavailable in this
mode>
Command is valid at this level of access, but not effective. Eg line rate
when in smart Exsync mode
Command not completed in time. Eg FPN/ PRNU calculation when no
external Exsync is present.
Error 07: Camera settings not saved>
Tried saving camera settings (rfs/ rus) but they cannot be saved.
Error 08: Unable to calibrate - tap outside
ROI>
Cannot calibrate a tap that is not part of the region of interest.
Error 09: The camera's temperature exceeds
the specified operating range>
Indicates that the camera has shut itself down to prevent damage from
further overheating.
