98 • Technical Specifications X64 Xcelera-CL PX4 User's Manual

External Signals Connector Bracket Assembly (Type 2) Pinout

The following table defines the signal pinout on the DB25 connector.

Refer to the table "J4: External Signals Connector " on

page 89 for signal descriptions.

DB25 Pin Number Signal J4 Connector Pin

Number

6 TRIG_0+ 19

19 TRIG_0- 20

7 TRIG_1+ 21

20 TRIG_1- 22

8 PHY_0+ 23

21 PHY_0- 24

9 PHY_1+ 25

22 PHY_1- 26

11 Strobe_0 28

24 GND 29

10 Strobe_1 30

14 GND 31

15 GND 38

16 GND 39

25 GND 40
