X64 Xcelera-CL PX4 User's Manual X64 Xcelera-CL PX4 Reference • 65
step = 1
CORACQ_PRM_BAYER_DECODER_SATURATION_WEIGHT_RED min = 0
max = 0
step = 1
CORACQ_PRM_BAYER_DECODER_SATURATION_WEIGHT_GRE
EN
min = 0
max = 0
step = 1
CORACQ_PRM_BAYER_DECODER_SATURATION_WEIGHT_BLU
E
min = 0
max = 0
step = 1
ACQ Related Parameters - CameraLink Full Mono
Acq Device (0):
Parameter Values
CORACQ_PRM_LABEL CameraLink Full Mono #1
CORACQ_PRM_EVENT_TYPE CORACQ_VAL_EVENT_TYPE_START_OF_FRAME
CORACQ_VAL_EVENT_TYPE_END_OF_FRAME
CORACQ_VAL_EVENT_TYPE_EXTERNAL_TRIGGER
CORACQ_VAL_EVENT_TYPE_NO_PIXEL_CLK
CORACQ_VAL_EVENT_TYPE_PIXEL_CLK
CORACQ_VAL_EVENT_TYPE_FRAME_LOST
CORACQ_VAL_EVENT_TYPE_DATA_OVERFLOW
CORACQ_VAL_EVENT_TYPE_EXTERNAL_TRIGGER_IGNORED
CORACQ_VAL_EVENT_TYPE_VERTICAL_TIMEOUT
CORACQ_PRM_SIGNAL_STATUS CORACQ_VAL_SIGNAL_HSYNC_PRESENT
CORACQ_VAL_SIGNAL_VSYNC_PRESENT
CORACQ_VAL_SIGNAL_PIXEL_CLK_PRESENT
CORACQ_PRM_DETECT_PIXEL_CLK Not available
CORACQ_PRM_DETECT_HACTIVE 0
CORACQ_PRM_DETECT_VACTIVE 0
CORACQ_PRM_FLAT_FIELD_SELECT 0
CORACQ_PRM_FLAT_FIELD_ENABLE TRUE
FALSE
CORACQ_CAP_SERIAL_PORT_INDEX Supported
Camera Related Capabilities - CameraLink Medium Color RGB
Acquisition Device (1)
Capability Values
CORACQ_CAP_CONNECTOR_TYPE CORACQ_VAL_CONNECTOR_TYPE_CAMLINK (0x2)
CORACQ_CAP_CONNECTOR_CAMLINK
Pin - 01 CORACQ_VAL_SIGNAL_NAME_NO_CONNECT (0x1)
CORACQ_VAL_SIGNAL_NAME_PULSE0 (0x8)
CORACQ_VAL_SIGNAL_NAME_PULSE1 (0x10)
CORACQ_VAL_SIGNAL_NAME_GND (0x4000)
