Sapera Servers & Resources
Servers and Resources
The following table describes the X64 Xcelera-CL PX4 Full board
Servers Resources
Name Type Name Index Description
Xcelera-CL_PX4_1
(default firmware)
Acquisition CameraLink Full Mono 0
Full configuration,
monochrome output, Camera #1
CameraLink Full Color
RGB #1
1
Full configuration,
RGB output, Camera #1
Xcelera-CL_PX4_1
(10 tap firmware)
Acquisition
CameraLink 10 Tap
Parallel Mono #1
0
Full configuration,
10 Tap Format 2, Camera #1
Xcelera-CL_PX4_1
(Bayer firmware)
Acquisition
CameraLink
Bayer #1
0
Base configuration,
Bayer Decoder, Camera #1
The following table describes the X64 Xcelera-CL PX4 Dual board
Servers Resources
Name Type Name Index Description
Xcelera-CL_PX4_1
(default Base firmware)
Acquisition CameraLink Base Mono 1 0
Base configuration,
monochrome Camera #1
CameraLink Base Mono 2 1
Base configuration,
monochrome Camera #2
CameraLink Base RGB 1 2
Base configuration,
color RGB Camera #1
CameraLink Base RGB 2 3
Base configuration,
color RGB Camera #2
Xcelera-CL_PX4_1
(Medium firmware)
Acquisition
CameraLink Medium
Monochrome 1
0
Medium configuration,
monochrome Camera #1
CameraLink Medium
Color RGB 1
1
Medium configuration,
RGB Camera #1
Xcelera-CL_PX4_1
(Bayer firmware)
Acquisition
CameraLink Base
Bayer 1
0
Base configuration,
Bayer Decoder, Camera #1
CameraLink Base
Bayer 2
1
Base configuration,
Bayer Decoder, Camera #2
