X64 Xcelera-CL PX4 User's Manual Technical Specifications • 87

J3: Camera Link Connector 2

Medium and Full Camera Link sources require cables connected to both J2 and J3.

Name Pin # Type Description

MEDIUM _X0- 25 Input Neg. Medium Data 0

MEDIUM _X0+ 12 Input Pos. Medium Data 0

MEDIUM _X1- 24 Input Neg. Medium Data 1

MEDIUM _X1+ 11 Input Pos. Medium Data 1

MEDIUM _X2- 23 Input Neg. Medium Data 2

MEDIUM _X2+ 10 Input Pos. Medium Data 2

MEDIUM _X3- 21 Input Neg. Medium Data 3

MEDIUM _X3+ 8 Input Pos. Medium Data 3

MEDIUM _XCLK- 22 Input Neg. Medium Clock

MEDIUM _XCLK+ 9 Input Pos. Medium Clock

TERM 20 Term Resistor

TERM 7 Term Resistor

FULL_X0- 19 Input Neg. Full Data 0

FULL _X0+ 6 Input Pos. Full Data 0

FULL _X1- 18 Input Neg. Full Data 1

FULL _X1+ 5 Input Pos. Full Data 1

FULL _X2- 17 Input Neg. Full Data 2

FULL _X2+ 4 Input Pos. Full Data 2

FULL _X3- 15 Input Neg. Full Data 3

FULL _X3+ 2 Input Pos. Full Data 3

FULL _XCLK- 16 Input Neg. Full Clock

FULL _XCLK+ 3 Input Pos. Full Clock

GND 1, 13, 14, 26 Ground

Dalsa X64 Xcelera-CL PX4 User Manual
