54 • X64 Xcelera-CL PX4 Reference X64 Xcelera-CL PX4 User's Manual
X64 Xcelera-CL PX4 Supported Parameters
The tables below describe the Sapera capabilities supported by the X64 Xcelera-CL PX4 Full (i.e. default
firmware is loaded). Unless specified, each capability applies to both boards or all mode configurations
and all acquisition modes.
The information here is subject to change. Capabilities should be verified by the application because new
board driver releases may change product specifications.
Specifically the X64 Xcelera-CL PX4 family is described in Sapera as:
• Board Server: Xcelera-CL_PX4_1
• Acquisition Module: dependent on firmware used
Camera Related Capabilities - CameraLink Full Mono
Acq Device (0):
Capability Values
CORACQ_CAP_CONNECTOR_TYPE CORACQ_VAL_CONNECTOR_TYPE_CAMLINK (0x2)
CORACQ_CAP_CONNECTOR_CAMLINK (Pin – 01) CORACQ_VAL_SIGNAL_NAME_NO_CONNECT (0x1)
CORACQ_VAL_SIGNAL_NAME_PULSE0 (0x8)
CORACQ_VAL_SIGNAL_NAME_PULSE1 (0x10)
CORACQ_VAL_SIGNAL_NAME_GND (0x4000)
CORACQ_CAP_CONNECTOR_CAMLINK (Pin – 02) CORACQ_VAL_SIGNAL_NAME_NO_CONNECT (0x1)
CORACQ_VAL_SIGNAL_NAME_PULSE0 (0x8)
CORACQ_VAL_SIGNAL_NAME_PULSE1 (0x10)
CORACQ_VAL_SIGNAL_NAME_GND (0x4000)
CORACQ_CAP_CONNECTOR_CAMLINK (Pin – 03) CORACQ_VAL_SIGNAL_NAME_NO_CONNECT (0x1)
CORACQ_VAL_SIGNAL_NAME_PULSE0 (0x8)
CORACQ_VAL_SIGNAL_NAME_PULSE1 (0x10)
CORACQ_VAL_SIGNAL_NAME_GND (0x4000)
CORACQ_CAP_CONNECTOR_CAMLINK (Pin – 04) CORACQ_VAL_SIGNAL_NAME_NO_CONNECT (0x1)
