X64 Xcelera-CL PX4 User's Manual X64 Xcelera-CL PX4 Reference • 63
CORACQ_PRM_MASTER_MODE_HSYNC_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_PRM_MASTER_MODE_VSYNC_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_PRM_SHAFT_ENCODER_DROP min = 0 tick
max = 255 tick
step = 1 tick
CORACQ_PRM_SHAFT_ENCODER_ENABLE TRUE
FALSE
CORACQ_PRM_EXT_TRIGGER_FRAME_COUNT Default = 1 frame
CORACQ_PRM_INT_FRAME_TRIGGER_ENABLE TRUE
FALSE
CORACQ_PRM_INT_FRAME_TRIGGER_FREQ min = 1 milli-Hz
max = 1073741823 milli-Hz
step = 1 milli-Hz
CORACQ_PRM_SHARED_EXT_TRIGGER Not available
CORACQ_PRM_SHARED_CAM_RESET Not available
CORACQ_PRM_SHARED_CAM_TRIGGER Not available
CORACQ_PRM_SHARED_TIME_INTEGRATE Not available
CORACQ_PRM_SHARED_FRAME_INTEGRATE Not available
CORACQ_PRM_SHARED_STROBE Not available
CORACQ_PRM_STROBE_DELAY_2 min = 0 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_FRAME_LENGTH CORACQ_VAL_FRAME_LENGTH_FIX (0x1)
CORACQ_VAL_FRAME_LENGTH_VARIABLE (0x2)
CORACQ_PRM_FLIP Not available
CORACQ_PRM_SHARPNESS min = 0
max = 0
step = 1
CORACQ_PRM_EXT_TRIGGER_DURATION min = 0 µs
max = 65535 µs
step = 1 µs
CORACQ_PRM_TIME_INTEGRATE_DELAY min = 0 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_CAM_RESET_DELAY min = 0 µs
max = 0 µs
step = 1 µs
CORACQ_PRM_CAM_TRIGGER_DELAY min = 0 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_SHAFT_ENCODER_LEVEL CORACQ_VAL_LEVEL_422 (0x2)
CORACQ_PRM_WEN_ENABLE Not available
CORACQ_PRM_LUT_NENTRIES 256 entries
CORACQ_PRM_EXT_FRAME_TRIGGER_SOURCE (*) min = 0
max = 5
step = 1
CORACQ_PRM_EXT_LINE_TRIGGER_SOURCE (*) min = 0
max = 7
step = 1
CORACQ_PRM_EXT_TRIGGER_SOURCE (*) min = 0
max = 5
