66 • X64 Xcelera-CL PX4 Reference X64 Xcelera-CL PX4 User's Manual
Pin - 02 CORACQ_VAL_SIGNAL_NAME_NO_CONNECT (0x1)
CORACQ_VAL_SIGNAL_NAME_PULSE0 (0x8)
CORACQ_VAL_SIGNAL_NAME_PULSE1 (0x10)
CORACQ_VAL_SIGNAL_NAME_GND (0x4000)
Pin - 03 CORACQ_VAL_SIGNAL_NAME_NO_CONNECT (0x1)
CORACQ_VAL_SIGNAL_NAME_PULSE0 (0x8)
CORACQ_VAL_SIGNAL_NAME_PULSE1 (0x10)
CORACQ_VAL_SIGNAL_NAME_GND (0x4000)
Pin - 04 CORACQ_VAL_SIGNAL_NAME_NO_CONNECT (0x1)
Camera Related Parameters - CameraLink Medium Color RGB
Acquisition Device (1)
Parameter Values
CORACQ_PRM_CHANNEL CORACQ_VAL_CHANNEL_SINGLE (0x1)
CORACQ_PRM_FRAME CORACQ_VAL_FRAME_PROGRESSIVE (0x2)
CORACQ_PRM_INTERFACE CORACQ_VAL_INTERFACE_DIGITAL (0x2)
CORACQ_PRM_SCAN CORACQ_VAL_SCAN_AREA (0x1)
CORACQ_VAL_SCAN_LINE (0x2)
CORACQ_PRM_SIGNAL CORACQ_VAL_SIGNAL_DIFFERENTIAL (0x2)
CORACQ_PRM_VIDEO CORACQ_VAL_VIDEO_RGB (0x8)
CORACQ_PRM_PIXEL_DEPTH 8 bits, # LUT = 1, LUT format = CORDATA_FORMAT_COLORNI8
10 bits, # LUT = 1, LUT format = CORDATA_FORMAT_COLORNI10
12 bits, # LUT = 1, LUT format = CORDATA_FORMAT_COLORNI12
CORACQ_PRM_VIDEO_STD CORACQ_VAL_VIDEO_STD_NON_STD (0x1)
CORACQ_PRM_FIELD_ORDER CORACQ_VAL_FIELD_ORDER_NEXT_FIELD (0x4)
CORACQ_PRM_HACTIVE min = 1 pixel
max = 16777215 pixel
step = 1 pixel
CORACQ_PRM_HSYNC min = 4 pixel
max = 4294967295 pixel
step = 1 pixel
CORACQ_PRM_VACTIVE min = 1 line
max = 16777215 line
step = 1 line
CORACQ_PRM_VSYNC min = 0 line
max = 4294967295 line
step = 1 line
CORACQ_PRM_HFRONT_PORCH min = 0 pixel
max = 0 pixel
step = 1 pixel
CORACQ_PRM_HBACK_PORCH min = 0 pixel
max = 0 pixel
step = 1 pixel
CORACQ_PRM_COUPLING Not available
CORACQ_PRM_VFRONT_PORCH min = 0 line
max = 0 line
step = 1 line
CORACQ_PRM_VBACK_PORCH min = 0 line
