X64 Xcelera-CL PX4 User's Manual X64 Xcelera-CL PX4 Reference • 67
max = 0 line
step = 1 line
CORACQ_PRM_HFRONT_INVALID min = 0 pixel
max = 16777215 pixel
step = 1 pixel
CORACQ_PRM_HBACK_INVALID min = 0 pixel
max = 16777215 pixel
step = 1 pixel
CORACQ_PRM_VFRONT_INVALID min = 0 line
max = 16777215 line
step = 1 line
CORACQ_PRM_VBACK_INVALID min = 0 line
max = 16777215 line
step = 1 line
CORACQ_PRM_PIXEL_CLK_SRC CORACQ_VAL_PIXEL_CLK_SRC_EXT (0x2)
CORACQ_PRM_PIXEL_CLK_INT min = 20000000 Hz
max = 85000000 Hz
step = 1 Hz
CORACQ_PRM_PIXEL_CLK_11 20000000 Hz
CORACQ_PRM_PIXEL_CLK_EXT min = 20000000 Hz
max = 85000000 Hz
step = 1 Hz
CORACQ_PRM_SYNC CORACQ_VAL_SYNC_SEP_SYNC (0x4)
CORACQ_PRM_HSYNC_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_PRM_VSYNC_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_PRM_DETECT_HACTIVE 0 active pixel per line
CORACQ_PRM_DETECT_PIXEL_CLK Not available
CORACQ_PRM_DETECT_VACTIVE 0 lines per field
CORACQ_PRM_FRAME_INTEGRATE_METHOD Not available
CORACQ_PRM_FRAME_INTEGRATE_POLARITY Not available
CORACQ_PRM_TIME_INTEGRATE_METHOD CORACQ_VAL_TIME_INTEGRATE_METHOD_1 (0x1)
CORACQ_VAL_TIME_INTEGRATE_METHOD_2 (0x2)
CORACQ_VAL_TIME_INTEGRATE_METHOD_3 (0x4)
CORACQ_VAL_TIME_INTEGRATE_METHOD_4 (0x8)
CORACQ_VAL_TIME_INTEGRATE_METHOD_5 (0x10)
CORACQ_VAL_TIME_INTEGRATE_METHOD_6 (0x20)
CORACQ_VAL_TIME_INTEGRATE_METHOD_7 (0x40)
CORACQ_VAL_TIME_INTEGRATE_METHOD_8 (0x80)
CORACQ_PRM_CAM_TRIGGER_METHOD CORACQ_VAL_CAM_TRIGGER_METHOD_1 (0x1)
CORACQ_VAL_CAM_TRIGGER_METHOD_2 (0x2)
CORACQ_PRM_CAM_TRIGGER_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_PRM_CAM_TRIGGER_DURATION min = 1 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_CAM_RESET_METHOD CORACQ_VAL_CAM_RESET_METHOD_1 (0x1)
CORACQ_PRM_CAM_RESET_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_PRM_CAM_RESET_DURATION min = 1 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_CAM_NAME Default Area Scan
