86 • Technical Specifications X64 Xcelera-CL PX4 User's Manual
J2: Camera Link Connector 1
Name Pin # Type Description
BASE_X0- 25 Input Neg. Base Data 0
BASE_X0+ 12 Input Pos. Base Data 0
BASE_X1- 24 Input Neg. Base Data 1
BASE_X1+ 11 Input Pos. Base Data 1
BASE_X2- 23 Input Neg. Base Data 2
BASE_X2+ 10 Input Pos. Base Data 2
BASE_X3- 21 Input Neg. Base Data 3
BASE_X3+ 8 Input Pos. Base Data 3
BASE_XCLK- 22 Input Neg. Base Clock
BASE_XCLK+ 9 Input Pos. Base Clock
SERTC+ 20 Output Pos. Serial Data to Camera
SERTC- 7 Output Neg. Serial Data to Camera
SERTFG- 19 Input Neg. Serial Data to Frame Grabber
SERTFG+ 6 Input Pos. Serial Data to Frame Grabber
CC1- 18 Output Neg. Camera Control 1
CC1+ 5 Output Pos. Camera Control 1
CC2+ 17 Output Pos. Camera Control 2
CC2- 4 Output Neg. Camera Control 2
CC3- 16 Output Neg. Camera Control 3
CC3+ 3 Output Pos. Camera Control 3
CC4+ 15 Output Pos. Camera Control 4
CC4- 2 Output Neg. Camera Control 4
GND 1, 13, 14, 26 Ground
