X64 Xcelera-CL PX4 User's Manual Camera Link Interface • 101
Communication
Two LVDS pairs have been allocated for asynchronous serial communication to and from the camera and
frame grabber. Cameras and frame grabbers should support at least 9600 baud.
• SerTFG Differential pair with serial communications to the frame grabber.
• SerTC Differential pair with serial communications to the camera.
The serial interface protocol is one start bit, one stop bit, no parity, and no handshaking.
Camera Link Cables
For additional information on Camera Link cables and their specifications, visit the following web sites:
3 M
http://www.3m.com/us/electronics_mfg/interconnects/
(enter Camera Link as the search keyword)
Nortech Systems http://www.nortechsys.com/intercon/CameraLinkMain.htm
