X64 Xcelera-CL PX4 User's Manual X64 Xcelera-CL PX4 Reference • 53
Connector 1
Channel Link No. X
Connector 2
Channel Link No. Y
Connector 2
Channel Link No. Z
Bit
Name
Input/Output
Pin
Bit
Name
Input/Output
Pin
Bit
Name
Input/Output
Pin
D0_0 Tx0/Rx0 D3_2 Tx0/Rx0 D6_5 Tx0/Rx0
D0_1 Tx1/Rx1 D3_3 Tx1/Rx1 D6_6 Tx1/Rx1
D0_2 Tx2/Rx2 D3_4 Tx2/Rx2 D6_7 Tx2/Rx2
D0_3 Tx3/Rx3 D3_5 Tx3/Rx3 D7_0 Tx3/Rx3
D0_4 Tx4/Rx4 D3_6 Tx4/Rx4 D7_1 Tx4/Rx4
D0_5 Tx5/Rx5 D3_7 Tx5/Rx5 D7_2 Tx5/Rx5
D0_6 Tx6/Rx6 D4_0 Tx6/Rx6 D7_3 Tx6/Rx6
D0_7 Tx7/Rx7 D4_1 Tx7/Rx7 D7_4 Tx7/Rx7
D1_0 Tx8/Rx8 D4_2 Tx8/Rx8 D7_5 Tx8/Rx8
D1_1 Tx9/Rx9 D4_3 Tx9/Rx9 D7_6 Tx9/Rx9
D1_2 Tx10/Rx10 D4_4 Tx10/Rx10 D7_7 Tx10/Rx10
D1_3 Tx11/Rx11 D4_5 Tx11/Rx11 D8_0 Tx11/Rx11
D1_4 Tx12/Rx12 D4_6 Tx12/Rx12 D8_1 Tx12/Rx12
D1_5 Tx13/Rx13 D4_7 Tx13/Rx13 D8_2 Tx13/Rx13
D1_6 Tx14/Rx14 D5_0 Tx14/Rx14 D8_3 Tx14/Rx14
D1_7 Tx15/Rx15 D5_1 Tx15/Rx15 D8_4 Tx15/Rx15
D2_0 Tx16/Rx16 D5_2 Tx16/Rx16 D8_5 Tx16/Rx16
D2_1 Tx17/Rx17 D5_3 Tx17/Rx17 D8_6 Tx17/Rx17
D2_2 Tx18/Rx18 D5_4 Tx18/Rx18 D8_7 Tx18/Rx18
D2_3 Tx19/Rx19 D5_5 Tx19/Rx19 D9_0 Tx19/Rx19
D2_4 Tx20/Rx20 D5_6 Tx20/Rx20 D9_1 Tx20/Rx20
D2_5 Tx21/Rx21 D5_7 Tx21/Rx21 D9_2 Tx21/Rx21
D2_6 Tx22/Rx22 D6_0 Tx22/Rx22 D9_3 Tx22/Rx22
D2_7 Tx23/Rx23 D6_1 Tx23/Rx23 D9_4 Tx23/Rx23
LVAL Tx24/Rx24 D6_2 Tx24/Rx24 D9_5 Tx24/Rx24
FVAL Tx25/Rx25 D6_3 Tx25/Rx25 D9_6 Tx25/Rx25
D3_0 Tx26/Rx26 D6_4 Tx26/Rx26 D9_7 Tx26/Rx26
D3_1 Tx27/Rx27 LVAL Tx27/Rx27 LVAL Tx27/Rx27
