46 • X64 Xcelera-CL PX4 Reference X64 Xcelera-CL PX4 User's Manual
CORACQ_PRM_EXT_LINE_TRIGGER_SOURCE full description relative to trigger
type and X64 Xcelera-CL PX4 configuration used:
PRM
Value
X64 Xcelera-CL
PX4 configuration
& camera input
used
External Line Trigger
Signal used
External Shaft Encoder
Signal used
if
CORACQ_PRM_EXT_LINE_
TRIGGER_ENABLE = true
if
CORACQ_PRM_SHAFT_
ENCODER_ENABLE =true
0
Dual - Camera #1 Shaft Encoder Phase A Shaft Encoder Phase A
Dual - Camera #2 Shaft Encoder Phase B Shaft Encoder Phase B
Full - Camera #1 Shaft Encoder Phase A Shaft Encoder Phase A & B
1
Dual - Camera #1 Shaft Encoder Phase A Shaft Encoder Phase A
Dual - Camera #2 Shaft Encoder Phase A Shaft Encoder Phase A
Full - Camera #1 Shaft Encoder Phase A Shaft Encoder Phase A
2
Dual - Camera #1 Shaft Encoder Phase B Shaft Encoder Phase B
Dual - Camera #2 Shaft Encoder Phase B Shaft Encoder Phase B
Full - Camera #1 Shaft Encoder Phase B Shaft Encoder Phase B
3
Dual - Camera #1 n/a Shaft Encoder Phase A & B
Dual - Camera #2 n/a Shaft Encoder Phase A & B
Full - Camera #1 n/a n/a – use parameter value = 0
See "J4: External Signals Connector " on page 89 for shaft encoder input connector details.
CVI/CCF File Parameters Used
• External Line Trigger Source = prm value
• External Line Trigger Enable = true/false
• Shaft Encoder Enable = true/false
