X64 Xcelera-CL PX4 User's Manual X64 Xcelera-CL PX4 Reference • 69
CORACQ_PRM_CONNECTOR_HD_INPUT (*) Default = 0
CORACQ_PRM_CONNECTOR_VD_INPUT (*) Default = 0
CORACQ_PRM_CONNECTOR_RESET_TRIGGER_INPUT (*) Default = 0
CORACQ_PRM_TIME_INTEGRATE_PULSE1_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_PRM_TIME_INTEGRATE_PULSE1_DELAY min = 0 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_TIME_INTEGRATE_PULSE1_DURATION min = 0 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_CAM_IO_CONTROL (*) ?
CORACQ_PRM_CONNECTOR_EXPOSURE_INPUT (*) Default = 0
CORACQ_PRM_TIME_INTEGRATE_PULSE0_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_PRM_TIME_INTEGRATE_PULSE0_DELAY min = 0 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_TIME_INTEGRATE_PULSE0_DURATION min = 1 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_LINE_INTEGRATE_PULSE1_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_PRM_LINE_INTEGRATE_PULSE1_DELAY min = 0 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_LINE_INTEGRATE_PULSE1_DURATION min = 1 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_LINE_INTEGRATE_PULSE0_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_PRM_LINE_INTEGRATE_PULSE0_DELAY min = 0 µs
max = 65535 µs
step = 1 µs
CORACQ_PRM_LINE_INTEGRATE_PULSE0_DURATION min = 1 µs
max = 65535000 µs
step = 1 µs
CORACQ_PRM_VIDEO_LEVEL_MIN Default = 0 µV
CORACQ_PRM_VIDEO_LEVEL_MAX Default = 0 µV
CORACQ_PRM_CONNECTOR_LINE_TRIGGER_INPUT (*) Default = 0
CORACQ_PRM_CONNECTOR_LINE_INTEGRATE_INPUT (*) Connector #1, type 2, pin #1
CORACQ_PRM_CONNECTOR_LINESCAN_DIRECTION_INPUT (*) Default = 0
CORACQ_PRM_CAMLINK_CONFIGURATION CORACQ_VAL_CAMLINK_CONFIGURATION_BASE (0x1)
CORACQ_PRM_DATA_VALID_ENABLE TRUE
FALSE
CORACQ_PRM_DATA_VALID_POLARITY CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_PRM_CONNECTOR_PIXEL_CLK_OUTPUT (*) Default = 0
CORACQ_PRM_CONNECTOR_WEN_OUTPUT (*) Default = 0
CORACQ_PRM_WEN_POLARITY Not available
CORACQ_PRM_TIMESLOT CORACQ_VAL_TIMESLOT_1 (0x1)
