25
MAGFLO
â
D & W
MAG 1100, integral/remote mount/separate4. Dimensions and weight
4.1
Sensor MAG 1100
4. Dimensions and weight
1
) 0.5" shorter when the AISI terminal box is used. (Ex and high temperature 390°F).
2
) With signal converter MAG 5000 or MAG 6000 installed, weight is increased by approx. 1.8 lbs.
The total built-in length "L" [inch] before assembling depends on the gasket selected.
Size EPDM Graphite PTFE(Teflon) Without gasket Grounding ring
1
/
4
" 2.52 2.60 2.75 2.52 3.03
3
/
8
" 2.52 2.60 2.75 2.52 3.03
1
/
2
" 2.56 2.60 2.75 2.52 3.03
1" 3.15 3.19 3.35 3.10 3.62
1
1
/
2
" 3.74 3.78 3.94 3.70 4.21
2" 4.13 4.17 4.33 4.05 4.61
2
1
/
2
" 5.12 5.15 5.31 5.05 5.60
3" 6.10 6.14 6.30 6.00 6.57
4" 7.28 7.31 7.48 7.20 7.76
The MAG 1100
1
/
4
" and
3
/
8
" are prepared for assembly with the
1
/
2
" pipe connection.
The built-in length "L" varies dependent on the gasket choice:
Without gasket EPDM Graphite Teflon
L [inch] 5.9 5.9 6.0 6.1
Size A
1
) B
1
) A
1
B
1
D D
i
D
i
D
p
D
G
Weight
2
)
(Al
2
O
3
) (PFA)
[inch] [inch] [inch] [inch] [inch] [inch] [inch] [inch] [inch] [lbs]
1
/
4
" 6.14 7.13 12.16 13.15 1.90 0.24 0.68 1.34 10.6
3
/
8
" 6.14 7.13 12.16 13.15 1.90 0.39 0.39 0.53 1.34 10.6
1
/
2
" 6.14 7.13 12.16 13.15 1.90 0.59 0.63 0.68 1.57 10.6
1" 6.46 7.72 12.48 13.74 2.50 0.98 1.02 1.12 2.20 10.8
1
1
/
2
" 6.93 8.58 12.95 14.61 3.31 1.57 1.50 1.71 2.95 16.5
2" 7.24 9.25 13.27 15.27 4.00 1.97 1.97 2.15 3.54 20.3
2
1
/
2
" 7.64 10.00 13.66 16.02 4.72 2.56 2.60 2.68 4.41 26.5
3" 7.87 10.47 13.90 16.50 5.24 3.15 3.19 3.25 4.88 33.1
4" 8.39 11.50 14.41 17.52 6.26 3.94 3.94 4.22 5.91 48.5
Signal converter removal clearance
