Danfoss MAGFLO MAG 5000 User Manual

26
MAGFLO
â
D & W
4.2
Sensor MAG 1100 FOOD
MAG 1100 FOOD, integral or remote mount and separate
4. Dimensions and weight
Size L A A
1
B B
1
D D
i
D
i
Weight
1
)
(Al
2
O
3
) (PFA)
[inch] [inch] [inch] [inch] [inch] [inch] [inch] [inch] [lbs]
3
/
8
" 2.52 6.14 12.16 7.40 13.43 2.52 0.39 0.39 4.8
1
/
2
" 2.52 6.14 12.16 7.40 13.43 2.52 0.59 0.63 4.8
1" 3.11 6.46 12.48 7.98 14.01 3.05 0.98 1.02 4.9
1
1
/
2
" 3.70 6.93 12.95 8.72 14.74 3.58 1.57 1.50 7.5
2" 4.09 7.24 13.27 9.59 15.61 4.68 1.97 1.97 9.2
2
1
/
2
" 5.16 7.64 13.66 10.20 16.22 5.12 2.56 2.60 12.0
3" 6.14 7.87 13.90 10.93 16.95 6.10 3.15 3.19 15.0
4" 7.32 8.39 14.41 11.99 18.01 7.20 3.94 3.94 22.0
1
) With signal converter MAG 5000 or MAG 6000 installed, weight is increased by approx. 1.8 lbs.
Built-in length
Size A
[inch]
3
/
8
" 3.90
1
/
2
" 3.90
1" 4.45
1
1
/
2
" 4.96
2" 6.06
2
1
/
2
" 6.50
3" 7.87
4" 8.86
Signal converter removal clearance
