MAGFLO
â
9. Service
Commissioning
9. Service
Power on converter,
display light on
YES
NO
NO
Check cables/connections
Check connection board
Check pins in converter
multiplug - OK
Correct fault
YES
NO
Output
readings OK
Converter
defective
YES
Display defect
Change display
Output and display
readings OK ?
NO
NO
Check cables/connections
Check connection board
Check pins in converter
multiplug - OK
Correct fault
Error triangles flashing
NO
YES
Check error table
Converter OK -
Check settings/application
Check installation/sensor/
grounding connection etc.
YES
YES
Often problems with unstable/wrong measurements occur due to insufficient/wrong grounding or
potential equalization. Please check connection. If OK, the MAGFLO
â
converter can be checked
as described under 9.1 and sensor under 9.3.
9.1
Converter check list
When checking MAGFLO
â
installations for malfunction the easiest method to check the signal
converter is to replace it with another MAG 5000/6000 converter with a similar power supply.
A replacement can easily be done as all settings are stored in and downloaded from the
SENSORPROM
â
unit - no extra settings need to be made.
If no spare converter is available - then check converter according to check table.
