29
MAGFLO
â
D & W
4. Dimensions and weight
mm inch kgs lbs kgs lbs kgs lbs kgs lbs kgs lbs
25 1" N/A N/A N/A N/A 4 9 4 9 N/A N/A
40 1½” N/A N/A N/A N/A 7 15 6 13 N/A N/A
50 2" N/A N/A 9 20 N/A N/A 8 20 N/A N/A
65 2½” N/A N/A 10.7 24 N/A N/A 11 24 N/A N/A
80 3" N/A N/A 11.6 26 N/A N/A 13 28 N/A N/A
100 4" N/A N/A 15.2 33 N/A N/A 19 41 N/A N/A
125 5" N/A N/A 20.4 45 N/A N/A 24 52 N/A N/A
150 6" N/A N/A 26 57 N/A N/A 29 64 N/A N/A
200 8" 48 106 48 106 N/A N/A 56 124 N/A N/A
250 10" 64 141 69 152 N/A N/A 79 174 N/A N/A
300 12" 76 167 86 189 N/A N/A 110 243 N/A N/A
350 14" 100 220 116 255 N/A N/A 131 289 N/A N/A
400 16" 127 280 144 317 N/A N/A 165 364 N/A N/A
450 18" 152 335 178 393 N/A N/A 176 388 N/A N/A
500 20" 184 405 232 512 N/A N/A 235 518 N/A N/A
600 24" 258 568 343 736 N/A N/A 345 761 N/A N/A
700 28" 315 693 350 772 N/A N/A N/A N/A 309 681
750 30" N/A N/A N/A N/A N/A N/A N/A N/A 480 1058
800 32" 410 904 442 975 N/A N/A N/A N/A 421 928
900 36" 512 1129 550 1213 N/A N/A N/A N/A 539 1188
1000 40" 650 1433 732 1614 N/A N/A N/A N/A 670 1477
42" N/A N/A N/A N/A N/A N/A N/A N/A 700 1544
1100 44" N/A N/A N/A N/A N/A N/A N/A N/A 1100 2426
1200 48" 990 2183 1106 2439 N/A N/A N/A N/A 1030 2271
AWWA
Nominal size
PN 10
PN 16 PN 40 Class 150
MAG 5100 W weight
The effect of temperature on
working pressure
MAG 5100 W
Metric (Pressure in bar)
Sizes 25 mm, 40 mm & > 600 mm
Flange spec. Flange Temperature °C
rating -5 10 50 90
EN 1092-1 PN 10 10.0 10.0 9.7 9.4
PN 16 16.0 16.0 15.5 15.1
PN 40 40.0 40.0 38.7 37.7
ANSI B16.45 150 lb 19.7 19.7 19.3 18.0
AWWA C-207 Class D 10.3 10.3 10.3 10.3
Sizes 50 mm to 600 mm
EN 1092-1 PN 10 10.0 10.0 10.0 8.2
PN 16 10.0 16.0 16.0 13.2
PN 40 10.0 40.0 40.0 32.9
ANSI B16.45 150 lb 10.0 19.7 19.7 16.2
Imperial (Pressure in Psi)
Sizes 1", 1½”, & > 24"
Flange spec. Flange Temperature °F
rating 25 50 125 200
EN 1092-1 PN 10 145 145 141 136
PN 16 232 232 225 219
PN 40 580 580 561 547
ANSI B16.45 150 lb 286 286 280 261
AWWA C-207 Class D 150 150 150 150
Sizes 2" to 24"
EN 1092-1 PN 10 145 145 145 119
PN 16 145 232 232 191
PN 40 145 580 580 477
ANSI B16.45 150 lb 145 286 286 235
