Danfoss VLT AQUA Drive FC 202 Programming Guide

13-10 Comparator Operand
Array [6]
Option: Function:
Select the variable to be
monitored by the comparator.
[0] DISABLED
[1] Reference %
[2] Feedback %
[3] Motor speed
[4] Motor Current
[5] Motor torque
[6] Motor power
[7] Motor voltage
[8] DC-link voltage
[9] Motor Thermal
[10] Drive thermal
[11] Heat sink temp.
[12] Analog input AI53
[13] Analog input AI54
[14] Analog input AIFB10
[15] Analog input AIS24V
[17] Analog input AICCT
[18] Pulse input FI29
[19] Pulse input FI33
[20] Alarm number
[21] Warning number
[22] Analog input x30 11
[23] Analog input x30 12
[24] Sensorless Flow
[25] Sensorless Pressure
[26] Flow Totalized Volume
[27] Flow Actual Volume
[28] Flow
[29] Number Of Pump Running
[30] Counter A
[31] Counter B
[34] Analog Input x48/2
[35] Temp Input x48/4
[36] Temp Input x48/7
[37] Temp Input x48/10
[38] Derag Counter
[40] Analog input x42/1
[41] Analog input x42/3
[42] Analog input x42/5
[46] AI53 scaled
[47] AI54 scaled
[48] AI53 unit
[49] AI54 unit
[50] FALSE
[51] TRUE
[52] Control ready
[53] Drive ready
[54] Running
[55] Reversing
13-10 Comparator Operand
Array [6]
Option: Function:
[56] In range
[60] On reference
[61] Below reference, low
[62] Above ref, high
[65] Torque limit
[66] Current Limit
[67] Out of current range
[68] Below I low
[69] Above I high
[70] Out of speed range
[71] Below speed low
[72] Above speed high
[75] Out of feedback range
[76] Below feedback low
[77] Above feedback high
[80] Thermal warning
[82] Mains out of range
[85] Warning
[86] Alarm (trip)
[87] Alarm (trip lock)
[90] Bus OK
[91] Torque limit & stop
[92] Brake fault (IGBT)
[94] Safe stop active
[100] Comparator 0
[101] Comparator 1
[102] Comparator 2
[103] Comparator 3
[104] Comparator 4
[105] Comparator 5
[110] Logic rule 0
[111] Logic rule 1
[112] Logic rule 2
[113] Logic rule 3
[114] Logic rule 4
[115] Logic rule 5
[120] SL Time-out 0
[121] SL Time-out 1
[122] SL Time-out 2
[123] SL Time-out 3
[124] SL Time-out 4
[125] SL Time-out 5
[126] SL Time-out 6
[127] SL Time-out 7
[130] Digital input DI18
[131] Digital input DI19
[132] Digital input DI27
[133] Digital input DI29
[134] Digital input DI32
[135] Digital input DI33
[150] SL digital output A
Parameter Description Programming Guide
MG20OB02 Danfoss A/S © 05/2018 All rights reserved. 117
