13-10 Comparator Operand
Array [6]
Option: Function:
[151] SL digital output B
[152] SL digital output C
[153] SL digital output D
[154] SL digital output E
[155] SL digital output F
[160] Relay 1
[161] Relay 2
[162] Relay 3
[163] Relay 4
[164] Relay 5
[165] Relay 6
[166] Relay 7
[167] Relay 8
[168] Relay 9
[180] Local referecnce active
[181] Remote reference active
[182] Start command
[183] Drive stopped
[185] Drive in hand mode
[186] Drive in auto mode
[187] Start command given
[190] Digital input x30/2
[191] Digital input x30/3
[192] Digital input x30/4
[193] Digital input x46/1
[194] Digital input x46/3
[195] Digital input x46/5
[196] Digital input x46/7
[197] Digital input x46/9
[198] Digital input x46/11
[199] Digital input x46/13
[204] System On Ref
[205] No Flow
[206] Dry Pump
[207] End of Curve
[208] Broken Belt
[209] ECB Drive Mode
[210] ECB Bypass Mode
[211] ECB Test Mode
[212] Emergency Mode
[240] Totalized Vol in thousands
[241] Totalized Vol in millions
[242] Totalized Vol in billions
[243] Totalized Vol in trillions
[245] Actual Vol in thousands
[246] Actual Vol in millions
[247] Actual Vol in billions
[248] Actual Vol in trillions
[249] Therm. Sensor Temp.
13-11 Comparator Operator
Array [6]
Option: Function:
[0] < Select [0] < for the result of the evaluation to be
true, when the variable selected in
parameter 13-10 Comparator Operand is smaller
than the xed value in
parameter 13-12 Comparator Value. The result is
false, if the variable selected in
parameter 13-10 Comparator Operand is greater
than the xed value in
parameter 13-12 Comparator Value.
[1] ≈ (equal) Select [1] ≈ for the result of the evaluation to be
true, when the variable selected in
parameter 13-10 Comparator Operand is approxi-
mately equal to the xed value in
parameter 13-12 Comparator Value.
[2] > Select [2] > for the inverse logic of option [0] <.
[5] TRUE
longer
than..
[6] FALSE
longer
than..
[7] TRUE
shorter
than..
[8] FALSE
shorter
than..
13-12 Comparator Value
Array [6]
Range: Function:
Size
related*
[-100000 -
100000 ]
Enter the trigger level for the
variable that is monitored by this
comparator. This is an array
parameter containing comparator
values 0–5.
Parameter Description
VLT
®
AQUA Drive FC 202
118 Danfoss A/S © 05/2018 All rights reserved. MG20OB02
33
