ALARMS FOR VARIABLES AND CONSTANTS
The following illustration gives the general format for the display of alarms for
variables and constants:
- Line 1 (nnnnnnnn) represents the name of the variable or constant
which can be from 1 to 8 characters in length.
- Line 2 (xxxxxxxxxxxxxxxx) represents the alarm message, which can
be from 1 to 16 characters in length.
nnnnnnnn
xxxxxxxxxxxxxxxx
Typical alarm messages are:
- SYSTEM ALARM
- RATE LIMIT
- HI-HI LIMIT
- HI LIMIT
- LO LIMIT
- LO-LO LIMIT
- USER ALARM
The following illustration shows an example of an alarm display for a variable:
- O I L H I H I is the name of the variable alarm (high-high oil level):
- HI-HI LIMIT isthealarm message indicating the oil level is
above the high-high alarm limit.
OILHIHI
HI-HI LIMIT
________________________________________________________________________________________________________________________________________
SECTIONSECTION 55
86
