MODEL 2500 CONTROL AND DISPLAY DEVICES
The DANIEL INDUSTRIES MODEL 2500 INSTRUMENTATION SYSTEM
MICROCOMPUTER operating commands and data are entered, changed, and
displayed on the instrument’s front panel as illustrated in Figure 2-1. The front
panel is composed of the following:
- Three status light-emitting diodes (LED)
- Backlighted, two-line liquid crystal display (LCD)
- 16-key keypad (symmetrically arranged in four columns with four
keys in each column)
Additionally, The MODEL 2500 instrument may be controlled from either the local
front panel on the instrument itself or from a remote front panel connected to the
MODEL 2500 by means of a serial port.
Figure 2-1
