MODELMODEL 2500_______________________________________________________2500_______________________________________________________
CONSTANT/VARIABLE STATUS
The status of the constant or variable can be from 1 to 8 characters in length, and
in the illustrations in the following sub-section entitled TYPE OF DISPLAY, the
statuses are represented by the characters "sssssss". Definitions of typical status
display abbreviations are shown in the following table.
Status Display
Abbreviation
Definition
MANUAL Value used in the calculations is
currently the FIXED value.*
blank Value used in the calculations is
currently the LIVE value.*
LIVE Current value from transmitter input*
FIXED Operator-entered over-ride value*
Z SCALE Zero-scale value
F SCALE Full-scale value
LO LO Lo Lo alarm limit
LO Lo alarm limit
HI Hi alarm limit
HI HI Hi Hi alarm limit
RATE Rate of change limit
* Detailed explanations of the status abbreviations MANUAL, blank, LIVE,
and FIXED are provided in Section 6, under the sub-section entitled,
CHANGING THE STATUS OF A VARIABLE.
________________________________________________________________________________________________________________________________________
SECTIONSECTION 55
81
