CHANGING AND DISPLAYING A FIXED VALUE
The steps involved in changing and displaying a FIXED value on the MODEL
2500 LCD screen are as follows:
- Begin with the following illustrated display screen message.
C3TEMP LIVE
20.0 DEGF
- Press the DOWN arrow key to move to the third selection of the
C3TEMP menu and display the FIXED value of the variable as
illustrated in the following display screen.
C3TEMP FIXED
30.0 DEGF
The status field has changed from LIVE to FIXED, and the
operator-entered value (30.0 DEGF) has replaced the value being sent
by the transmitter (20.0 DEGF).
If the password has been entered, the operator may change this value
by keying in a new value and then pressing the ENTER key. If an
error is made while keying in the new value, the DOWN arrow key
may be used to backspace the cursor over the error.
________________________________________________________________________________________________________________________________________
SECTIONSECTION 66
94
