MODELMODEL 2500_______________________________________________________2500_______________________________________________________
PROCEDURE OF DATA ENTRY AT INITIAL STARTUP
The procedural steps for entering data during initial startup of the DANIEL
INDUSTRIES MODEL 2500 INSTRUMENTATION SYSTEM are as follows:
1. Turn on the MODEL 2500 and ensure that the normal start-up message,
which is illustrated below, is displayed.
D513024A
13-JAN-89 08:34
2. Unlock the front panel for data entry by pressing the DOWN arrow on the
front panel keypad several times until the message "SYSTEM
COMMANDS" appears on the lower text line of the LCD screen display.
_________________________________________________________
NOTE! Continuously holding down the key, rather than
pressing it several times will cause the display to
scroll rapidly through the MAIN MENU and may
result in overshooting the SYSTEM COMMANDS
sub-menu. If this occurs, continue to press the
DOWN arrow one step at a time until the message
SYSTEM COMMANDS reappears.
_________________________________________________________
3. Press the ENTER key once.
4. Press the DOWN arrow one step at a time until the message "UNIT
PASSWORD" appears.
5. Pressing the ENTER key once.
________________________________________________________________________________________________________________________________________
SECTIONSECTION 33
37
