____________________________________________________________________________________________________________ MODELMODEL 25002500
CHANGING AND DISPLAYING THE FULL-SCALE VALUE FOR A
VARIABLE
The steps involved in changing and displaying the full-scale value for a variable
on the MODEL 2500 LCD screen are as follows:
- Begin with the following illustrated display screen message.
C3TEMP ZSCALE
25.0 DEGF
- Press the DOWN arrow key to move to the fifth selection of the
C3TEMP menu and display the full-scale value of the variable as
illustrated in the following display screen.
C3TEMP FSCALE
125 DEGF
The data displayed in the illustration above are the value and
engineering units displayed when the C3TEMP transmitter sends a
full-scale signal (125 DEGF) to the MODEL 2500.
If the password has been entered, an operator may change this value
by keying in a new value and then pressing the ENTER key. If an
error is made while keying in the new value, the DOWN arrow key
may be used to backspace the cursor over the error.
________________________________________________________________________________________________________________________________________
SECTIONSECTION 66
96
