EXAMPLES FOR LOCATING AND ENTERING DATA TABLES
This section presents examples involved in locating, displaying and entering data
on data tables. In addressing the steps or procedures involved in accomplishing this,
the specific application example chosen to demonstrate this will be "Application
Number 51119110".
In this application example, a typical table, TABLE 18, is used. TABLE 18
contains values of K, which are used in determining a Reynolds number factor by
means of a calculation. K values depend on the orifice meter tap type and the value
of BETA, which is the ratio between the orifice diameter and the pipe diameter.
TABLE 18, as it would typically appear in printed form, is illustrated below.
TABLE 18
TAPTYPE
12
BETA 0.100 0.607 0.604
BETA 0.125 0.608 0.604
BETA 0.150 0.611 0.604
BETA 0.175 0.614 0.604
BETA 0.200 0.618 0.604
BETA 0.225 0.623 0.605
BETA 0.250 0.628 0.605
BETA 0.275 0.634 0.606
BETA 0.300 0.641 0.606
BETA 0.325 0.650 0.607
________________________________________________________________________________________________________________________________________
SECTIONSECTION 66
104
