MODELMODEL 2500_______________________________________________________2500_______________________________________________________
Pressing the DOWN arrow key when the first, or a subsequent,
selection is displayed on a menu, causes the next selection on the
same menu to appear, pressing the UP arrow causes the preceding
selection on the same menu to appear.
Pressing the EXIT key causes the display data to return to the menu
from which it was selected. In the case of the above illustrated display
screen, pressing the EXIT key once would cause it to return to the
ANALOG INPUTS sub-menu, and pressing the EXIT key a second
time would cause it to return to the INPUT CHANNELS sub-menu.
CHANGING THE STATUS OF A VARIABLE
The steps involved in changing the status of a variable on the MODEL 2500 are
as follows:
- Begin with the following illustrated display screen message, which
indicates the first channel of the lower level sub-menu ANALOG
INPUTS.
20. DEGF
C3TEMP
- Press the ENTER key to display the following illustrated sub-menu,
C3TEMP, of the ANALOG INPUTS lower level sub-menu.
C3TEMP
20. DEGF
On line 1 of the display screen, the variable name, C3TEMP, and the
status field, which has been left blank, indicate that the parameters
related to the variable can now be examined and changed if the unit
password has been entered and has not yet timed out.
________________________________________________________________________________________________________________________________________
SECTIONSECTION 66
91
