- Press the ENTER key to display the following illustrated sub-menu
showing that the status field message, which was blank, is now
changed to "MANUAL", and the operator-entered fixed value (30.0
DEGF) has replaced the value, 20.0 DEGF, being received from the
transmitter.
C3TEMP MANUAL
30. DEGF
_________________________________________________________
NOTE! If an input value, or any variable, is manually
overridden, the fixed value is the value actually used
for computations.
_________________________________________________________
- Press the ENTER key and notice that the LIVE status and value are
again shown, which indicates that the value used in the calculations
can be changed from live to fixed, or from fixed to live, as required.
- With MANUAL status displayed, press the EXIT key to display the
following illustrated display screen, which indicates that the value
being used in the calculations is the fixed value for this variable, and
that the display has returned to channel 1 of the ANALOG INPUTS
lower sub-menu.
30. DEGF
C3TEMP MANUAL
________________________________________________________________________________________________________________________________________
SECTIONSECTION 66
