____________________________________________________________________________________________________________ MODELMODEL 25002500
- Press the ENTER key, and the following illustrated sub-menu, INPUT
CHANNELS, appears on the top line of the display screen, and the
first lower sub-menu, ANALOG INPUTS, of the INPUT CHANNELS
sub-menu appears on the bottom line, which indicates that the INPUT
CHANNELS menu is active.
INPUT CHANNELS
ANALOG INPUTS
- Press the ENTER key, and in the following illustrated sub-menu,
channel 1 of the ANALOG INPUTS lower sub-menu, C3TEMP,
appears on the display screen.
20. DEGF
C3TEMP
A blank appears in the status field on the second line of the display
screen, which indicates that the value being transmitted by the
transmitter, the LIVE value, is the value currently being used in
calculations by the MODEL 2500. If the message "MANUAL"
appears in the status field, this indicates that the live value of the
variable has been overridden, and the value being shown is a fixed
value used for calculations.
- Press the DOWN arrow key, and the following illustrated sub-menu,
the second selection of the ANALOG INPUTS menu, C4TEMP,
appears on the display screen.
25. DEGF
C4TEMP
________________________________________________________________________________________________________________________________________
SECTIONSECTION 66
90
