Tabelle Action2
ID
RefGroup
RefTime
RefReader
Relais
PortOut
Elapse
RefReader
LED
RefTime
Relais
Description
Read an RFID chip on reader 1
1000
10
0
2
1
5
3
0
Opening normal for 5s.
Group (10; 20; 30) have
always entrance
1000
20
0
2
1
5
3
0
1000
30
0
2
1
5
3
0
1000
30
2
4
1
32400
5
0
door 2 open for 9h
(max. 16:00)
1000
30
2
6
1
32400
7
0
door 2 open for 9h
(max. 16:00)
1000
40
0
2
1
-1
3
0
command door open, return
1000
40
0
4
1
-1
5
0
command door open, return
Read an RFID chip on reader 2
2000
10
0
4
1
5
5
0
Opening normal for 5s.
Group (10; 20; 30) have
always entrance
2000
20
0
4
1
5
5
0
2000
30
0
4
1
5
5
0
2000
30
2
4
1
32400
5
0
door 3 open for 9h
(max. 16:00)
2000
30
2
6
1
32400
7
0
door 3 open for 9h
(max. 16:00)
2000
40
0
4
1
-1
5
0
command door open, return
2000
40
0
6
1
-1
7
0
command door open, return
Read an RFID chip on reader 3
3000
0
0
6
1
5
0
0
This action is for all Groups
are listed in the table “Loca-
tion”.
Tabele Location
ID
refGroup
refTime
refTimeNoPin
Description
100
10
1
0
Group 10, 20, 30 and 40 have access on this reader.
100
20
1
0
100
30
1
0
100
40
1
0
200
10
1
0
Group 20 can not use this entrance 2.
200
30
1
0
200
40
1
0
300
10
1
0
The Master of Garage and the facility manager can open this
door.
300
30
1
0
Tabele Identification
ID
Group
Pin
Menace
ActiveStart
ActiveEnd
Active
Description
1111
10
0
0
2005-01-01
2015-12-31
1
Master of Garage
2222
20
0
0
2005-01-01
2015-12-31
1
Skilled workers
3333
30
0
0
2005-01-01
2015-12-31
1
Facility manager
4444
40
0
0
2005-01-01
2015-12-31
1
Facility manager second RFID-chip,
only for closing the door
