DRAGON™
158
5
5.11.2 Copy DRAGON
M-Series
Procedure:
Using the slave reader and its OM-DRAGON™ cradle, follow the initialization
procedure in chapter 4 of this manual or from the Quick Reference Manual.
With the master DRAGON M (correctly configured reader), read the Copy
Configuration barcode below. Then place it onto an OM-DRAGON™ cradle
within 10 seconds. The reader will beep indicating the configuration has been
copied.
The configuration will be simultaneously sent over the RS232 interface of the
OM-DRAGON™. If this causes undesired effects disconnect the RS232 cable
between the PC and OM-DRAGON™ during this process.
Copy Configuration
i;;k
i;;k
i;;k
$+ZZ0$-
With the slave DRAGON M, read the Get Configuration barcode below. Then
place it onto the same OM-DRAGON™ cradle used in the step above. The
slave reader's address will not be changed.
Get Configuration
i;;k
i;;k
i;;k
$+ZZ2$-
The configuration will be copied from the master to the slave DRAGON M. The
slave DRAGON M signals the end of the procedure with a series of beeps. It is
now ready to be used with its own OM-DRAGON™ cradle.
Repeat the procedure above to configure other slave readers. The
OM-DRAGON™ can continue to configure slave readers until it receives
another command or data.
