5.11.3 Copy OM-DRAGON™
Procedure:
Using the slave reader and its OM-DRAGON™ cradle, read the Restore
Default barcode, set the radio address, and then read the RS232 interface
barcode from chapter 4 of this manual or from the Quick Reference Manual.
Connect the master OM-DRAGON™ and the slave OM-DRAGON™ (cradle to
be configured) together through two RS232 serial interface cables and external
power supply. Accessory cables and power supply are available from your
Datalogic distributor to provide this connection.
RS232 Cables: CAB363 & CAB364
or CAB320 & CAB328
Power Supply: PG12
Read the Configuration Copy barcode below with a reader. Then place it onto
the master OM-DRAGON™ cradle.
Copy Configuration
i;;k
i;;k
i;;k
$+ZZ3$-
The configuration will be copied from the master OM-DRAGON™ to the slave
OM-DRAGON™. The reader signals the end of the procedure with a series of
beeps.
Repeat the procedure above to configure other slave cradles.
Note: The master OM-DRAGON™ can be configured for any interface.
