7 TECHNICAL FEATURES
7.1 DRAGON™ D
STD HD LR
Electrical Features
Supply Voltage 4 to 20 Vdc
Consumption
@ 4V
@ 5V
@ 20 V
Sleep Mode
250 mA
170 mA
40 mA
2 mA
Laser Features
Light Source VLD between 630~680 nm
Scan Rate 35 ± 5 scans/sec
Power (max) in mW 0.9 mW 0.4 mW 1.4 mW
Scan Angle 42° 37° 23°
PCS minimum
(Datalogic Test Chart)
15% 40% 40%
Resolution maximum
mm
mils
0.08
3
0.06
2.5
0.25
10
Reading Field Width see reading diagrams (par. 7.6)
Laser Safety Class
(EN 60825-1 / CDRH)
2
Environmental Features
Working Temperature (°C) -10 to +50 0 to +40 -10 to +50
Storage Temperature (°C) -20 to +50
Humidity 90% non condensing
Drop resistance (on concrete) IEC 68-2-32 Test ED
Protection sealed against rain and dust
Mechanical Features
Weight (without cable) about 270 g.
Dimensions 203 x 117 x 69 mm
Material ABS and Polycarbonate molded with rubber
