DRAGON™
12
2
Adhesive strip seats
2.8.2 Fixed Desktop Use
For fixed desktop installation, use the adhesive strips.
1. If you are installing several cradles and you desire to align them, you can use
the alignment plate (see Alignment Plate Installation), otherwise continue with
step 2.
2. Carefully clean
the adhesive strip
seat of the base
to remove any
impurities that
could reduce
adhesion.
3. Remove the protective plastic
from one side of the adhesive
strips and stick them onto the
base surface.
4. Remove the plastic from the
other side of the strips and affix
the base to the table.
5. Insert the antenna in the
appropriate hole on the body of
the cradle and screw it
clockwise until tight.
