DRAGON™
168
7
7.3 OM-DRAGON™ / C-DRAGON™
OM-DRAGON™ C-DRAGON™
Electrical and General Features
Supply Voltage 9 to 28 Vdc
Power Consumption max. 8 W (charging) *
Indicators Charger on LED (red)
Charge completed LED (green)
Power/Data LED (yellow)
Recharge Time
NiMh / NiCd batteries
2 hours
Host Interfaces
RS232 300 to 19200 baud
WEDGE
IBM AT or PS/2, XT, PC Notebook, IBM SURE1, IBM 3153, 31xx, 32xx,
34xx, 37xx terminals, Wyse terminals, Digital VT terminals, Apple ADB
Bus supported
PEN Emulation
Selectable minimum pulse from 200 µS to 1.2 mS
Environmental Features
Working Temperature (°C) -10 to +40
Storage Temperature (°C) -20 to +60
Humidity 90% non condensing
Protection IP40
Mechanical Features
Weight (without cable) about 600 g.
Dimensions 185 x 115 x 104 mm
Material ABS
* Having a switching regulator inside, the OM-DRAGON™ and C-DRAGON™ draw
the same power, regardless of the supply voltage. i.e. as the input voltage increases
the current drawn decreases.
