DRAGON™ D/M READER DATA ENTRY
Beeper¹
Red LED Green LED Meaning
ON Laser ON
one beep²
ON Correct read of a code in normal mode
H L long TX buffer full (when FIFO is enabled) or TX
error between DRAGON™ M and OM-
DRAGON™
H long ON Successful advanced format concatenation
H H H Timeout expired – operation not completed
H H long Error in advanced data formatting
OFF Ready to read a code
¹ Only the Beeper Intensity command can modify these signals.
² The data entry good read tone is user-configurable with all the Beeper commands
in the Reading Parameters section.
For M-series readers, normally this results in two beeps; the first indicates that the
reader has decoded the code, the second indicates whether OM-DRAGON™ has
received the data. See also par.5.8.4.
DRAGON™M POWER
Beeper Green LED Meaning
10 short H 10 short blinks Low Battery
H M L Power off
H = high tone
M = medium tone
L = low tone
DRAGON™ M BIND, JOIN, COPY COMMANDS
Beeper¹
Green LED Meaning
Blinking Command accepted; reader ready to be inserted
into the cradle
L Success
H L long tones Failure
