Datalogic Dragon User Manual

DRAGON™
176
A
PEN EMULATION
DESCRIPTION STRING
Operating mode
interpret (does not require
$+ or $-) $]
transparent (does not require
$+ or $-) $[
Minimum output pulse
200µs
DG0
400µs
DG1
600µs
DG2
800µs
DG3
1 ms
DG4
1.2 ms
DG5
Conversion to Code 39 and
Code 128
disable conversion to Code 39
(D series only)
DA0
enable conversion to Code 39
DA1
enable conversion to Code 128
(M series only)
DA2
Output level normal
DD0
inverted
DD1
Idle level normal
DE0
inverted
DE1
Overflow narrow overflow
DH0
medium overflow
DH1
wide overflow
DH2
Inter-Block delay (100 ms)
CK00-CK99
NETWORK
DESCRIPTION STRING
RS485 Network Disable Network
RZ0
Enable RS485 Slave
RZ1
Enable RS485 Master
RZ2
Slave Address Range Minimum Address
JB0000-1999
Maximum Address
JC0000-1999
Network Baud Rate 9600
JE0
19200
JE1
38400
JE2
Warning Message not transmitted
JG0
transmitted
JG1
Master Header no header
JA00
one character
JA01x
two characters
JA02xx
three characters
JA03xxx
four characters
JA04xxxx
five characters
JA05xxxxx
six characters
JA06xxxxxx
seven characters
JA07xxxxxxx
eight characters
JA08xxxxxxxx
x = Hex value from
00 to FE representing an ASCII character
