Datalogic Dragon User Manual

HOST CONFIGURATION STRINGS
179
A
DATA FORMAT (continued)
NOT FOR PEN EMULATION INTERFACES
DESCRIPTION STRING
Field Adjustment Disable
EF0
right addition
EFa0d
left addition
EFa1d
right deletion
EFa2d
left deletion
EFa3d
Field Adjustment Character
EGe
Character Replacement disable character replacement
EO0
first character replacement
EO1afg
second character replacement
EO2afg
third character replacement
EO3afg
Address Stamping disable reader address stamping
RU0
enable reader address stamping
RU1
disable cradle address stamping
RW0
enable cradle address stamping
RW1
Address Delimiter disable reader address delimiter
RV0
enable reader address delimiter and select
character
RV1h
disable cradle address delimiter
RY0
enable cradle address delimiter and select
character
RY1h
Time Stamping Disable
IL0
hour/minutes/seconds/month/day/year
IL1
hour/minutes/seconds/day/month/year
IL2
hour/minutes/seconds
IL3
month/day/year
IL4
day/month/year
IL5
Time Stamping Delimiter disable time stamping delimiter
IM0
enable time stamping delimiter and select
character
IM1h
a = ASCII character.
d = a number from the Hex/Numeric Table
e, f, g h = HEX values representing an ASCII character
a = ASCII character of the DATALOGIC STANDARD Code Identifier from the table on page 65.
d = a number in the range
01-32 from the Hex/Numeric Table
e = Hex value from
00 to FE
f = Hex value of the character to be replaced from
00 to FE
g
= Hex value of the new character to insert from 00 to FE
FF = replace with no new character (remove character)
h = a HEX value in the range from
00 - FE representing the ASCII character.
