Datalogic DS5100-X200 User Manual

READING FEATURES
91
6
6.1.1 Tilt Angle for Advanced Code Reconstruction
The most important parameter in Advanced Code Reconstruction is the value of the
maximum tilt angle (maximum) under which the code reconstruction process is still
possible.

Laser Beam
= tilt angle

0° to

max
Figure 72 – Tilt Angle
The decoder will be able to read the label with a tilt angle between
+  max and -  max as shown in the following figure:
Conveyor
Laser Beam
No Read
No Read
- 
+ 
0°
OK
OK
OK
OK
OK
No Read
Figure 73 – Reading Zones with  Max
