6.3 PERFORMANCE
The reading performance of the DS5100 scanner depends in part on the focus position
setting.
1x00 (Linear Medium Range Models)
Focus
Max Code Resolution
Reading Distance on 0.50 mm (20 mils) codes
F = 30 Near
0.20 mm (8 mils)
20 cm (7.9 in) - 50 cm (19.7 in)
F = 40 Med
0.25 mm (10 mils)
25 cm (9.8 in) - 70 cm (27.6 in)
F = 60 Far
0.38 mm (15 mils)
40 cm (15.7 in) - 100 cm (39.4 in)
1x05 (Linear Medium Range Subzero Models)
Focus
Max Code Resolution
Reading Distance on 0.50 mm (20 mils) codes
F = 30 Near
0.20 mm (8 mils)
22 cm (8.7 in) - 50 cm (19.7 in)
F = 40 Med
0.25 mm (10 mils)
27 cm (10.6 in) - 68 cm (26.8 in)
F = 60 Far
0.38 mm (15 mils)
41 cm (16.1 in) - 96 cm (37.8 in)
2x00 (Linear Long Range Models)
Focus
Max Code Resolution
Reading Distance on 0.50 mm (20 mils) codes
F = 45 Near
0.25 mm (10 mils)
30 cm (11.8 in) - 72 cm (28.3 in)
F = 65 Med
0.30 mm (12 mils)
45 cm (17.7 in) - 110 cm (43.3 in)
F = 75 Far
0.38 mm (15 mils)
58 cm (22.8 in) - 140 cm (55.1 in)
1x20 (OM Medium Range Models)
Focus
Max Code Resolution
Reading Distance on 0.50 mm (20 mils) codes
F = 30 Near
0.20 mm (8 mils)
18 cm (7.1 in) - 47 cm (18.5 in)
F = 40 Med
0.25 mm (10 mils)
23 cm (9.1 in) - 67 cm (26.4 in)
F = 60 Far
0.38 mm (15 mils)
39 cm (15.4 in) - 95 cm (37.4 in)
1x25 (OM Medium Range Subzero Models)
Focus
Max Code Resolution
Reading Distance on 0.50 mm (20 mils) codes
F = 30 Near
0.20 mm (8 mils)
20 cm (7.9 in) - 47 cm (18.5 in)
F = 40 Med
0.25 mm (10 mils)
25 cm (9.8 in) - 65 cm (25.6 in)
F = 60 Far
0.38 mm (15 mils)
40 cm (15.7 in) - 90 cm (35.4 in)
2x20 (OM Long Range Models)
Focus
Max Code Resolution
Reading Distance on 0.50 mm (20 mils) codes
F = 45 Near
0.25 mm (10 mils)
28 cm (11.0 in) - 69 cm (27.2 in)
F = 65 Med
0.30 mm (12 mils)
43 cm (16.9 in) - 107 cm (42.1 in)
F = 75 Far
0.38 mm (15 mils)
55 cm (21.7 in) - 135 cm (53.2 in)
