DS5100 REFERENCE MANUAL
50
3
3.2.1 Mounting DS5100
Using the DS5100 mounting bracket you can quickly and easily obtain standard mounting
positions (i.e. 15° Skew angles) for the reader as shown in the following figures:
Figure 23 – Positioning with L Shape Mounting Bracket
Skew
-45° -15° 0° 15° 45°
Pitch
