DS5100 REFERENCE MANUAL
132
9
9 TECHNICAL FEATURES
ELECTRICAL FEATURES
Input Power
Supply Voltage
10 - 30 Vdc; (24 Vdc ± 10% for Subzero models)
Maximum Consumption
xx00 (Standard)
xx20 (OM)
xx05 (Subzero)
xx25 (OM Subzero)
0.6 - 0.2 A; 6 W
0.75 - 0.25 A; 7.5 W
1.2 A; 28.8 W @ 24 Vdc
1.3 A; 31.2 W @ 24 Vdc
Communication Interfaces
Main Serial Interface
SW programmable: RS232; RS485 FD
Baudrate
1200 - 115200
Auxiliary
RS232
Baudrate
1200 - 115200
ID-NET
RS485 Half-Duplex
Baudrate
Up to 1 MBaud
Built-In Ethernet models
10/100 Mbit/s (supports TCP/IP, EtherNet/IP, Modbus TCP, Profinet-IO Class A)
Built-In Profinet-IO models
100 Mbit/s (supports Profinet-IO Class B, EBC)
Inputs
Input 1 (External Trigger), Input 2
Optocoupled, polarity insensitive
Voltage
10 to 30 Vdc
Current Consumption
12 mA max.
Minimum Pulse Duration
5 ms.
Outputs
Output 1, Output 2
Optocoupled
V
CE
30 Vdc max.
Collector Current
40 mA continuous max.; 130 mA pulsed max.
V
CE saturation
1V max. at 10 mA
Power Dissipation
80 mW max. at 45 C (ambient temperature)
OPTICAL FEATURES
Light Source
Semiconductor laser diode
Wave Length
In the range 630 to 680 nm
Safety Class
Class 2 - EN 60825-1; CDRH
READING FEATURES (Note 1)
Scan Rate (software programmable)
800 scans/sec
Aperture Angle
65°
Oscillating Amplitude (OM models)
40° ± 2° (-5° to 35°)
Oscillating Frequency (OM models)
0.2 to 20 Hz; 5 Hz max @ 40°; 20 Hz max @ 10°
Maximum Reading Distance
See reading diagrams
Maximum Resolution
ENVIRONMENTAL FEATURES
STD and OM
Subzero
Operating Temperature (Note 2)
0° to +50 C (+32° to +122 °F)
-35° to +50 C (-31° to +122 °F) (Note 3)
Storage Temperature
-20° to +70 C (-4° to +158 °F)
-35° to +70 C (-31° to +158 °F)
Humidity max.
90% non condensing
Vibration Resistance (Note 4)
14 mm @ 2 to 10 Hz; 1.5 mm @ 13 to 55 Hz;
EN 60068-2-6
2 g @ 70 to 500 Hz; 2 hours on each axis
Shock Resistance
30g; 11 ms;
EN 60068-2-27
3 shocks on each axis
Protection Class – EN 60529
IP65
Ambient Light Rejection
30,000 LUX
Note 1: Further details given in par. 6.3.
Note 2: If the reader is used in high temperature environments (over 40 C), use of the Beam Shutter is advised (see the
Genius configuration program) and/or a thermally conductive support (such as the metal bracket provided).
Note 3: The Operating Temperature is guaranteed under the following conditions: no direct ventilation on the scanner, fixed
working environment (no rapid temperature changes). At -35 °C, a 20 min warm-up period is required before the
scanner is ready to read barcodes.
Note 4: Product not installed on provided bracket.
