Datalogic DS5100-X200 User Manual

xiv
DS5100-X400
Profinet-IO Models
Figure C
1
Warning and Device Class Labels
7
Indicator LEDs
2
Power – Trigger Input Connector
8
Network LEDs
3
Profinet-IO – EBC Network Connectors
9
Power On LED
4
Laser Beam Output Window
10
Focus Adjustment Screw
5
Mounting Holes (7)
11
X-PRESS™ Push Button
6
Display
Connector block rotates to 90° position.
2
4
11
1
3
6
7
8
9
10
5
