ALTERNATIVE CONNECTIONS FOR ETHERNET MODELS
141
B
Scanner
USER INTERFACE
Vext
9/8
2
Vdc
Figure 85 - NPN Output Connection
CAUTION: For NPN output connections, the external interface voltage (Vext)
must not exceed the scanner power supply source voltage (Vdc) otherwise
correct output functioning cannot be guaranteed.
