Datalogic DS5100-X200 User Manual

xvi
DS5100-XX05
Subzero™ Models
Figure E
1
Warning and Device Class Labels
7
Indicator LEDs
2
Power – Serial Interfaces – I/O Connector
8
Network LEDs
3
Ethernet Connector
9
Power On LED
4
Laser Beam Output Window w/ heater
10
Focus Adjustment Screw
5
Mounting Holes (7)
11
X-PRESS™ Push Button
6
Display
12
Subzero™ Logo
Connector block rotates to 90° position.
9
10
11
12
2
4
5
7
3
5
6
1
8

Datalogic DS5100-X200 Specifications

General

Brand	Datalogic
Model	DS5100-X200
Category	Barcode Reader
Language	English
