Product Reference Guide 1-1
Chapter 1
Introduction
This Product Reference Guide contains comprehensive instructions on
scanner or scanner/scale installation. Either model may be termed “scan-
ner” for the purpose of simplicity in this manual. Also included are feature
configuration using special programming feature bar code labels and
advanced user information as described in the following chapter descrip-
tions.
Manual Overview
Chapter 1, Introduction, outlines the manual’s contents, details features
and specifications, provides regulatory and safety information, and lists
the symbologies (bar code types) the scanner will read.
Chapter 2, Site Preparation and Installation, presents physical dimen-
sions for the scanner or scanner/scale and popular accessories, and pro-
vides counter preparation and installation procedures. Cable routing,
connection and testing are additionally detailed in this chapter.
Chapter 3, Operation and Maintenance, contains use and maintenance
instructions; providing details about operator controls, programming and
diagnostic modes, scale “zeroing” and calibration. Scanner and scale rou-
tine maintenance is also outlined in this chapter.
Chapter 4, Problem Isolation, outlines the three scanner/scale test modes:
Selftest, Operational Tests and Diagnostic Tests. Procedures for system
problem and troubleshooting flowcharts to aid in problem resolution are
also presented in this chapter.
Chapter 5, Calibration, explains scale calibration and verification proce-
dures, including procedures for calibrating the scale in pounds as well as
kilograms.
