Controls and Indicators
Product Reference Guide A-5
Scale Zero Push Button
The Scale Zero Push Button is used for multiple functions as listed in
Tabl e A - 3 .
NOTE
The Scale Zero Push Button has no function in a “scanner only”
model.
The button must be configured to enable standard functions, or Scale
Diagnostics will not be an available feature. Reference Chapter 6,
Scanner Button Options for programming details.
Table A-3. Scale Zero Push Button Functions
PRESS
DURATION
FUNCTION COMMENT
Momentary Zero Scale
When programmed to do so, the yellow LED should be lit when no
weight is on the scale, indicating scale at zero. If it is not, press the
switch to zero the scale.
4 Seconds
Scale Diagnostics
Mode
a
This mode allows system support personnel to troubleshoot prob-
lems with the scale. Momentarily press the Scale Zero Push Button
or cycle power to exit Scale Diagnostics Mode.
a. Diagnostics Mode is meant for use by trained systems support personnel. Users should not need to ini-
tiate this function under normal circumstances.

Datalogic MAGELLAN 8300 Specifications

General

Read rate (max)	3900 reads/s
Decoding standards	1D, GS1 DataBar
Standard interfaces	Keyboard Wedge, RS-232
USB 2.0 ports quantity	1
Input voltage	100 - 250 V
Product color	Metallic
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	130 mm
