Datalogic MAGELLAN 8300 Product Reference Guide

2-10 Magellan
®
8300/8400
Service Access
The scanner and scanner/scale have been engineered to allow performance
of all routine service and maintenance (such as “zeroing” and calibration)
without removing the scanner from the checkstand. Additionally all cable
connections made at the scanner can be connected and removed while the
unit is sitting on the countertop. The installer should provide service
access to all remaining cable connectors as well as the AC/DC Power Sup-
ply (if installed).

Datalogic MAGELLAN 8300 Specifications

General

Read rate (max)	3900 reads/s
Decoding standards	1D, GS1 DataBar
Standard interfaces	Keyboard Wedge, RS-232
USB 2.0 ports quantity	1
Input voltage	100 - 250 V
Product color	Metallic
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	130 mm
